Day159 - MLOps Review: Data Engineering Fundamentals (2)
Designing Machine Learning Systems: Modes of Dataflow & Batch / Real-Time Processing
Modes of Dataflow
How data moves between services in ML and production systems
In modern machine learning systems, data rarely flows through a single process. Most real-world systems are composed of multiple services, often running in separate processes or even across different machines. These services need to communicate and share data, and how this communication happens—what we call dataflow—is a fundamental part of scalable system design.
Data Passing through Databases
The most straightforward and familiar approach is writing data to a database, which another process then reads from—for example, processing A records customer orders in a MySQL database. Additionally, periodically processing queries in the same database to analyze recent orders.
It is beneficial that it is easy to implement and suitable for batch systems and data archiving. However, it is challenging since both processes must access the same database, which is not always practical, for example, when different companies are involved. High latency makes it unsuitable for real-time or low-latency applications like fraud detection or ride pricing.
This method works well for batch analytics and offline workflows, but is too slow and rigid for dynamic, interactive applications.
Data Passing through Services (Request-Driven)
This is the most common mode in service-oriented or microservice architectures. In this model, one process requests data from another via a network call. The systrem is request-driven, meaning communication only happens when one service explicitly makes a request.
For instance, in a ride-sharing app like Lyft, the price optimization service must calculate the ideal fare for a ride. It sends requests to the driver management service to obtain supply data and to the ride management service for demand data. All services can be deployed, maintained, and scaled separately, making this architecture highly modular and extensible.
Common Protocols
It includes REST (Representational State Transfer), which is stateless and widely used over HTTP for public APIs, and RPC (Remote Procedure Call), which mimics function calls and is more common for internal, low-latency microservice-to-microservice communication. The pros of these protocols are clean interfaces and modularity, ease of documentation and testing, and strong support from modern development stacks such as Flask, FastAPI, and gRPC.
However, they also have cons, including tight coupling between services, synchronous communication that can break the chain if one service is down, and fragility under scale, where increasing the number of services can lead to tangled and hard-to-maintain request paths.
Data Passing Through Real-Time Transport (Event-Driven)
As systems become more complex, real-time streaming architectures offer a more decoupled, scalable solution.
Instead of services requesting data from each other, each service broadcasts events to a central broker (e.g., Kafka, Kinesis). Other services subscribe to these events based on topics of interest.
This setup is known as:
- Event-driven architecture
- Publish-subscribe (pubsub) model
For instance, let’s revisit our ride-sharing app. The driver management service publishes the predicted number of available drivers every minute. Meanwhile, the ride management service publishes expected ride demand. The price optimization service subscribes to both topics to calculate surge pricing dynamically.
The pros are as follows: loose coupling, which means that data producers and consumers don’t need to know about each other; high availability, as the broker retains the event for later if a consumer service goes down; and scalability, since more services can be added without modifying the producers.
Broker Responsibilities involve temporarily holding events (in memory or disk-backed), routing events to the appropriate consumers, and enforcing retention policies (e.g., deleting events after 7 days).
PubSub systems like Kafka and Kinesis broadcast data to all topic subscribers, while message queues such as RabbitMQ and RocketMQ deliver messages to specific intended recipients.
Real-time transports form the backbone of data-intensive ML systems, enabling real-time feature generation, model scoring, fraud detection, and more.
Batch vs. Stream Processing
How do we process data from a database or stream once it is in the system?
Batch Processing:
Batch processing operates on historical data stored in data lakes or warehouses. It runs on a schedule, such as nightly aggregation jobs, and utilizes tools like MapReduce, Apache Spark, or Airflow.
Stream Processing:
In contrast, stream processing operates on real-time data as it flows through the system. It handles events as they arrive, allowing for rapid responses like detecting fraudulent transactions within one second. Standard tools for stream processing include Apache Flink, Kafka Streams, Spark Streaming, or KSQL.
Batch Features:
Batch processing features often involve slowly-changing attributes, such as user age or average driver rating. This method is less sensitive to latency and typically computes values once a day, storing them in feature stores.
Streaming Features:
Streaming features focus on rapidly changing values, such as the number of drivers available at any moment or the current surge pricing. These features require real-time computation and are essential for live model scoring and responsive machine learning systems.
Stream Processing Engines
To manage complex stream computations like joins, aggregations, and windowing, you’ll need specialized stream processing engines:
- Apache Flink: High performance, scalable, supports event-time processing.
- KSQL (Kafka’s SQL engine): SQL abstraction over streaming data.
- Spark Streaming: Micro-batch processing of streams using Spark APIs.
Stream processing is more complex than batch processing. Because data is unbounded and arrives out of order, it must maintain state, such as tracking past events to compute real-time metrics. The system must also handle variable loads and still meet latency guarantees.
However, modern stream engines are robust and scalable, and even support stateful streaming, making them ideal for ML applications like:
- Real-time pricing
- Credit risk scoring
- Fraud detection
- Real-time personalization
In real-world ML systems, you’ll need both batch and streaming architectures:
| Task | Example | Dataflow Mode |
|---|---|---|
| Daily model training | Retrain fraud model with new logs | Batch (ETL + offline DB) |
| Real-time scoring | Predict if a transaction is fraudulent now | Stream (Kafka + Flink) |
| Feature store updates | Update user rating once a day | Batch |
| Dynamic features | # of transactions in the last minute | Stream |
Modern ML systems must be built on flexible, scalable data infrastructure that combines:
- Batch and stream processing
- Request-driven and event-driven data passing
- Relational and NoSQL storage models
